Technical Specification:
General Data:
| Model | SP10YD |
| Brand | Sakura |
| Continuous Power | 10 KVA |
| Continuous Power | 8.0 KW |
| Standby Power | 11 KVA |
| Standby Power | 8.8 KW |
| Volts | 220V |
| Frequency | 50HZ |
| Number of Phase | 3 |
| Engine RPM | 1500 |
| Power Factor | 0.8 |
Engine General Data:
| Engine Brand | Yangdong |
| Model | YD385D |
| Fuel | Diesel |
| Number of Cylinders | 3 |
| Fuel Tank Capacity | 70 L |
| Cooling System | Water Cooled |
Alternator General Data:
| Brand | Sakura |
| Type | Brushless |
| Model | SA164G11 |
| Th. Class | H |
| Protection | IP23 |
| AVR | SX460 |
Dimension and Noise Level:
| Length | 190 cm |
| Width | 85 cm |
| Height | 114 cm |
| Weight | 660 KG |
| Sound From 7 mt | 68 dBA |
Fuel Consumption:
| 25% Load | N/A |
| 50% Load | 1.5 L/H |
| 75% Load | 2.0 L/H |
| 100% Load | 2.6 L/H |
Useable applications: Light, Fan, TV, Computer and other heavy-duty home and office equipment. The powerful engine can provide heavy load duty. Home, office and corporate use
Engine: Yangdong YD385D, water-cooled diesel engine. 50°C water tank radiator made with 100% copper wires without any aluminium materials. Yangdong diesel engine is very popular all over in the world
Power: Prime power 10 kVA, Standby power 11 kVA
Alternator: SAKURA brushless alternator, SA164G11, IP23, H insulation class
Electric starting system: Smart electric key starting system make your generator operate easier. You just need to twist the key towards the off on indicator. It is super easy to operate. Recoil backup option also available.
Fuel: Diesel engine generator. You need 2.6-litre fuel per hour in 100% load, but fuel consumption will less if your generator run in lower load. Fuel tank capacity 70 litre
Noise level: In a distance of 7 mitres operating noise level will be 68 dBA
Running Hours: 8 hours
Warranty:
Warranty Information:
1 Year Local Seller Warranty.
Installation Charge: Free.
Notes: Cable & other accessories costs will bear by the buyer.
