Technical Specification:
General Data:
Model | |
Brand | Sakura |
Continuous Power | 100 KVA |
Continuous Power | 80 KW |
Standby Power | 110 KVA |
Standby Power | 88 KW |
Volts | 220V / 380V |
Frequency | 50HZ |
Number of Phase | 3 |
Engine RPM | 1500 |
Power Factor | 0.8 |
Engine General Data:
Engine Brand | Perkins |
Model | 1104C-44TAG2 |
Fuel | Diesel |
Number of Cylinders | 4 |
Fuel Tank Capacity | 100L |
Cooling System | Water Cooled |
Alternator General Data:
Brand | Stamford |
Type | Brushless |
Model | UCI274C |
Th. Class | H |
Protection |
|
AVR |
|
Dimension and Noise Level:
Length | 240 cm |
Width | 90 cm |
Height | 140 cm |
Weight | 1629 KG |
Sound From 7 mt | 70 dBA |
Fuel Consumption:
25% Load |
|
50% Load | 11.8 L/H |
75% Load | 17.1 L/H |
100% Load | 22.6 L/H |
Useable applications: Building and workplace, data center, factories, commercial center, Industrial power backup use
Engine: Perkins 1104C-44TAG2 more power output than competing products with close displacement, the power of the 3‐cylinder engine can reach the same level as 4‐cylinder ones of competitor
Power: Prime power 100 KVA/ 80KW, Standby power 110 KVA/ 88KW
Alternator: STAMFORD, UCI274C, IP23, H insulation class alternator
Starting System: Electronic starting system
Fuel Type: Diesel
Noise level: In the distance of 7 miters the operating noise level will be 70 dBA
Running Hours: 8 hours
Warranty:
Warranty Information:
1 Year Local Seller Warranty.
Installation Charge: Free.
Notes: Cable & other accessories costs will bear by the buyer.
