Technical Specification:
General Data:
| Model | SP30YD |
| Brand | Sakura |
| Continuous Power | 30 KVA |
| Continuous Power | 24 KW |
| Standby Power | 33 KVA |
| Standby Power | 26.4 KW |
| Volts | 220V / 380V |
| Frequency | 50HZ |
| Number of Phases | 3 Ph |
| Engine RPM | 1500 |
| Power Factor | 0.8 |
Engine General Data:
| Engine Brand | Yangdong |
| Model | Y4100D |
| Fuel | Diesel |
| Number of Cylinders | 4 |
| Fuel Tank Capacity | 70 L |
| Cooling System | Water Cooled |
Alternator General Data:
| Brand | Sakura |
| Type | Brushless |
| Model | SA222 |
| Th. Class | H |
| Protection | IP23 |
| AVR |
Dimension and Noise Level:
| Length | 225 cm / 7.4 ft |
| Width | 85 cm / 2.8 ft |
| Height | 114 cm / 5 ft |
| Weight | 835 KG |
| Sound From 7 mt | 69 dBA |
Fuel Consumption:
| 25% Load | 2.5 L/H |
| 50% Load | 3.9 L/H |
| 75% Load | 5.4 L/H |
| 100% Load | 7.0 L/H |
Useable applications: Heavy-duty, Home and Office equipment
Control Panel: ComAp AMF/DEEPSEA DSE6020
Engine: Yangdong Y4100D, water-cooled diesel engine
Power: Standby Power 33 KVA/ 26.4KW Prime Power 30 KVA/ 24KW
Alternator: Copper Alternator
Starting System: Electronic starting system
Fuel Type: Diesel
Noise level: In the distance of 7 meters operating noise level will be 69 dBA
Running Hours: 8 hours
Warranty: 1 Year.
Installation Charge: Free.
Notes: Buyer will bear cable & other accessories costs.
The picture may vary from the actual product.
