Technical Specification:
General Data:
| Model | SP80YD |
| Brand | Sakura |
| Continuous Power | 75 KVA |
| Continuous Power | 60 KW |
| Standby Power | 80 KVA |
| Standby Power | 64 KW |
| Volts | 220V / 380V |
| Frequency | 50HZ |
| Number of Phase | 3 Ph |
| Engine RPM | 1500 |
| Power Factor | 0.8 |
Engine General Data:
| Engine Brand | Yangdong |
| Model | Y4110ZLD |
| Fuel | Diesel |
| Number of Cylinders | 4 |
| Fuel Tank Capacity | 80 L |
| Cooling System | Water Cooled |
Alternator General Data:
| Brand | Sakura |
| Type | Brushless |
| Model | SA224G80 |
| Th. Class | H |
| Protection | IP23 |
| AVR | SX460 |
Dimension and Noise Level:
| Length | 242cm / 7.4ft |
| Width | 92cm / 3ft |
| Height | 145cm / 4.7ft |
| Weight | 1220 KG |
| Sound From 7 mt | 70 dBA |
Fuel Consumption:
| 25% Load | 4.8 L/H |
| 50% Load | 8.7 L/H |
| 75% Load | 12.6 L/H |
| 100% Load | 17.1 L/H |
Useable applications: Light, Fan, TV, Fridge, Air-conditioned, Oven, Air heater and so on.heavy duty corporate use. Backup power for school, college, hospital, clinic, restaurants
Engine: Yangdong engine family continues to set new standards in the compact engine market. Developed alongside customers to fulfil their needs in the generator set. These new ElectropaKs provide compact power, from a robust family of 3 and 4 cylinder diesel engines designed to provide economic and durable operation at prime and standby duties, hitting the key power nodes required by the power generation industry
Power: Prime Power 75 KVA, Standby Power 80 KVA
Alternator: SAKURA, IP23, H insulation class
Starting System: Smart electric key starting system make your generator operate easier. You just need to twist the key towards the off on indicator. It is super easy to operate. Recoil backup option also available.
Fuel Type: Diesel engine generator. You need 5-litre fuel per hour in 100% load, but fuel consumption will less if your generator run in lower load. Fuel tank capacity 80 litre
Noise level: in the distance of 7 mitres operating noise level will be 70 dBA
Running Hours: 8 hours
Warranty:
Warranty Information:
1 Year Local Seller Warranty.
Installation Charge: Free.
Notes: Cable & other accessories costs will bear by the buyer.
