Technical Specification:
General Data:
| Model | SP33YD |
| Brand | Sakura |
| Continuous Power | 30 KVA |
| Continuous Power | 24 KW |
| Standby Power | 33 KVA |
| Standby Power | 26.4 KW |
| Volts | 220V / 380V |
| Frequency | 50HZ |
| Number of Phase | 3 |
| Engine RPM | 1500 |
| Power Factor | 0.8 |
Engine General Data:
| Engine Brand | Yangdong |
| Model | Y4102D |
| Fuel | Diesel |
| Number of Cylinders | 4 |
| Fuel Tank Capacity | 70 L |
| Cooling System | Water Cooled |
Alternator General Data:
| Brand | Sakura |
| Type | Brushless |
| Model | SA184G33 |
| Th. Class | H |
| Protection | IP23 |
| AVR | ±1% |
Dimension and Noise Level:
| Length | 7.5 ft |
| Width | 3.8 ft |
| Height | 4.25 ft |
| Weight | 985KG |
| Sound From 7 mt | 68 dBA |
Fuel Consumption:
| 25% Load | N/A |
| 50% Load | 4.6 L/H |
| 75% Load | 6.9 L/H |
| 100% Load | 9.2 L/H |
Useable application: Heavy-duty corporate use. Backup power for School, college, hospital, clinic, restaurants
Engine: Water-cooled diesel engine. 50°C water tank radiator made with 100% copper wires without any aluminum materials. Yangdong diesel engine is very popular all over in the world.
Power: Prime power 30KVA/24KW Standby power 33 KVA/ 26.4 KW
Alternator: SAKURA brushless alternator, IP23, H insulation class
Starting System: Smart electric key starting system makes your generator operate more easier. You just need to twist the key towards the off on indicator. It is super easy to operate. Recoil backup options also available.
Fuel Type: Diesel engine generator. You need 7.2 -liter fuel per hour in 100% load, but fuel consumption will less if your generator run in lower load. Fuel tank capacity 70 liter
Noise level: In the distance of 7 miters the operating noise level will be 68 dBA
Running Hours: 8 hours
Warranty:
Warranty Information:
1 Year Local Seller Warranty.
Installation Charge: Free.
Notes: The buyer will bear cable & other accessories costs.
